22.5x9.00 Northstar 10x285mm Satin Black "Lunar" Hub Pilot Rear

Northstar 22.5” x 9 Forged Aluminum Rear Wheel – Satin Black

10-Hole Hub Pilot | 285.75mm Bolt Circle | Drive Axle Application

Upgrade your truck’s drive axles with the Northstar 22.5 x 9 Satin Black Forged Aluminum Rear Wheel, engineered for durability, performance, and bold style. Designed for hub-piloted, 10-hole applications, this wheel features a 285.75mm bolt circle and 220mm center bore for precise fitment on Class 8 trucks.

With its satin black finish, the wheel provides a sleek, modern appearance while resisting corrosion and road wear. Built from forged aluminum, it delivers maximum strength while reducing weight compared to steel, improving fuel efficiency and overall handling. Rated at 9,900 lbs @ 130 PSI, it’s ready for the heaviest vocational and highway demands.

Wheel Specifications

• Size: 22.5” x 9

• Finish: Satin Black (Rear)

• Position: Drive Axle Application

• Bolt Pattern: 10-Hole Hub Pilot, 285.75mm Bolt Circle

• Hub Bore: 220mm

• Offset: 7”

• Bolt Hole Diameter: 26mm

• Max Load: 9,900 lbs @ 130 PSI

• Warranty: 5 Years

Approved Tire Sizes

• 315/80R22.5

• 295/60R22.5

• 12R22.5

Replaces OEM/Comparable Parts

• Alcoa 89U64x

• Accuride 29730, 41730

Key Features

• Drive Axle Specific – Designed for rear/drive position applications on Class 8 trucks.

• Durable Satin Black Finish – Corrosion-resistant, modern look for vocational or highway fleets.

• Forged Aluminum Construction – Stronger and lighter than steel for improved efficiency.

• Heavy-Duty Load Rating – Supports up to 9,900 lbs at 130 PSI.

• Warranty Coverage – Backed by a 5-year manufacturer warranty.

The Northstar 22.5 x 9 Satin Black Forged Aluminum Rear Wheel combines strength, efficiency, and aggressive styling—making it the ideal upgrade for Class 8 drive axle applications.
