22.5x9.00 Northstar 10x285mm Front Hub Pilot Flat Face Satin Black "Lunar"

Northstar 22.5” x 9 Forged Aluminum Steer/Lift Axle Wheel – Satin Black

Steer/Lift Axle Application | Class 8 Trucks | Heavy-Duty Performance

Give your truck a sleek, modern upgrade with the Northstar 22.5 x 9 Satin Black Forged Aluminum Wheel, engineered specifically for steer and lift axle applications on Class 8 trucks. With its durable satin black finish, this wheel combines a bold appearance with the proven strength of forged aluminum construction.

Built for severe vocational and highway use, this wheel is designed to withstand the toughest loads while providing reduced weight compared to steel alternatives—helping improve handling, fuel efficiency, and overall performance.

Wheel Specifications

• Size: 22.5” x 9

• Position: Steer/Lift Axle Only

• Finish: Satin Black

• Bolt Pattern: 10-Hole Hub Pilot, 285.75mm Bolt Circle, 220mm Center Bore

• Inset: 3.12”

• Bolt Hole Diameter: 26mm

• Max Load: 9,900 lbs @ 130 PSI

• Warranty: 5 Years

Approved Tire Sizes

• 315/80R22.5

• 295/60R22.5

• 12R22.5

Replaces OEM/Comparable Parts

• Alcoa 89U63x

• Accuride 41012

Fits These Applications

• Class 8 Trucks

• Kenworth

• Peterbilt

• Freightliner

• Volvo

• International

• Mack

• Sterling

Key Features

• Durable Finish – Satin black coating for a sleek, corrosion-resistant look.

• Application-Specific – Designed for steer and lift axles on Class 8 trucks.

• Heavy-Duty Strength – Handles up to 9,900 lbs at 130 PSI.

• Proven Compatibility – Direct replacement for multiple Alcoa and Accuride part numbers.

• Warranty Coverage – Backed by a 5-year warranty for confidence and reliability.

The Northstar 22.5 x 9 Satin Black Forged Aluminum Wheel is built for strength, efficiency, and bold style—making it the perfect choice for steer and lift axle applications on today’s Class 8 trucks.
